IPv4 Sunset

All good (legacy) things must come to an end

Carsten Strotmann

Created: 2025-01-30 Thu 09:51

Agenda

  • The costs of dual-stack operation
  • Going IPv6-only
  • Islands of IPv4
  • IPv4 sunset in the Internet
  • Purchase

The cost of dual stack operation

Dual-Stack = Dual-Costs

  • Running a network in "Dual-Stack" mode with both IPv6 and IPv4 enabled creates additional costs
    • Additional network and routing configuration
    • Almost double the cost for network security (additional Firewall configuration, security audit, patches, more complexity = bad for security)
    • Extra work for troubleshooting, network issues can appear in either IPv6 or IPv4 or can be a interaction between the two protocols

Move IPv4 to "historic" status

  • While there has been attempts in the IETF to deprecate IPv4 (see IETF: End Work on IPv4), IPv4 is still needed in the Internet
    • The Internet will be "dual-stack" for a long time
    • External Services (Web-Server, E-Mail-Server, DNS-Server …) will require Dual-Stack connectivity for the foreseeable future
  • However it is possible to remove IPv4 in some (possibly not all) internal networks

Going "IPv6-only"

How to remove IPv4 from the network

  • In most networks, it is not feasible to remove IPv4 entirely
    • There are devices that don't (fully) support IPv6 and probably never will (e.g. older medical equipment, expensive factory machines, long living infrastructure devices)
    • But every network segment without IPv4 reduces the operational costs
    • Compare the costs of modernizing parts of the network infrastructure vs the costs of operating a "dual-stack" network

Selecting IPv6-only networks

  • Watch out for networks that …
    • have a low diversity in the devices operating systems and applications
    • have a high level of operational/administrative control over the devices in the network

Find "low hanging fruits"

  • Wireless Networks
    • Dedicated IPv6-only wireless network for the administration team
      • Good way to gain experience with IPv6-only networks
    • IPv6-only network for application developer
      • Developer of Apple iOS application require this, as they need to test applications in IPv6-only networks as demanded by the Apple App-Store

Find "low hanging fruits"

  • Guest-Wireless-Networks
    • Mobile devices (Phones, Tablets, Laptops) with "standard" applications (E-Mail, MS Office, Web-Browser) work fine in an IPv6-only environment
    • Use DNS64/NAT64 to allow access to IPv4-only resources on the Internet

Find "low hanging fruits"

  • Phone/VoIP networks
    • Limited number of device types
    • High level of operational control
    • Work with the vendor towards an IPv6-only VoIP network

Find "low hanging fruits"

  • Data-center networks
    • Data-Center networks are usually a very controlled environment (unless you offer hosting services)
    • IPv4 traffic can be terminated at the entry gateway to the data-center and "converted" to IPv6 (via protocol-proxy or application-proxy)

Find "low hanging fruits"

Find "low hanging fruits"

  • Administration networks (dedicated networks that are separate from the production networks)
    • Highly controlled
    • Limited number of users with higher-than-normal networking skills
    • be aware of monitoring applications
      • The Monitoring should still be able to reach IPv4 devices and services

Find "low hanging fruits"

  • Office Networks can be a candidate for IPv6-only networks

IPv6 "mostly"

IPv6 "mostly"

IPv6 "mostly"

  • Being a client/server protocol, DHCPv4 allows IPv4 to be selectively disabled on a per-host basis on a given network segment
  • Statistics from the DHCP server allow the admin to see the percentage of IPv6-only capable hosts (or if IPv4 is still needed in a particular network segment)

IPv6 "mostly" benefits

  • Drastically reduced IPv4 consumption
  • Controlled and incremental phase-out of IPv4
  • Reduced dependency on DHCPv4
  • Simplified troubleshooting due reduced impact of Happy Eyeballs

IPv6 "mostly" - Support for "IPv6-Only Preferred Option"

  • Kea DHCP since version 2.2
  • FreeBSD "dhcpd"
  • Trivial to implement this option in almost any DHCP server

IPv6 "mostly" - Support for "IPv6-Only Preferred Option"

  • Apple macOS versions starting with version 12.01
  • Apple iOS
  • Linux with Systemd since version 255
  • Microsoft plans to support the "IPv6-Only Preferred Option" in a future version of Windows 11

Keeping islands of IPv4 where needed

IPv4 in IPv6-only networks

IPv4 in IPv6-only networks

  • RFC 8925 defines a new DHCPv4 option that helps implementing IPv6-mostly (or IPv4-on-demand) segments where IPv6-only hosts coexist with legacy dual-stack devices: IPv6-Only Preferred Option for DHCPv4
    • Modern client machines can indicate that they can operate in an IPv6-only environment
    • DHCPv4 server can inform the DHCPv4 clients that the current attached network permits/prefers IPv6-only operation

Protocol Switch with the help of Application-Proxies

  • Application Proxies can be used to switch an TCP/IP connection from IPv4 to IPv6 or back
    • This is an application level gateway type of service
    • It can negatively affect performance and latency of a network or a service
    • Examples:
      • HTTP/Web-Proxy from an IPv6-only LAN towards the Dual-Stack Internet
      • HTTP Reverse-Proxy to offer a website on an IPv6-only web-server towards IPv4 clients
  • Application Proxies break end-to-end encryption and might not work with all protocols

Protocol Switch with the help of Protocol-Proxies

  • Protocol proxies, unlike application proxies, work at the routing layer.
    • The transport layer (TCP and UDP) and the application layer are not touched
    • The IP header of the packets is exchanged (IPv4 <-> IPv6)
    • Protocol proxies are also called protocol NAT systems
    • Popular protocol proxy variants are "IP/ICMP Translation Algorithm" (SIIT) and "SIIT-DC: Stateless IP/ICMP Translation for IPv6 Data Center Environments"

Protocol Switch with the help of Protocol-Proxies

  • Proxies can be set up separately from target systems and applications

    • They are transparent to most applications (i.e., no customization, such as a special proxy configuration, is required on either the client side or the target system)
    • Application and protocol proxies are available as open source Software (e.g. HA-Proxy, NGINX, OpenBSD "relayd") and as commercial solutions (mostly appliances).

IPv4 sunset on the Internet

Quality of IPv4

  • Because of the use of IPv4-in-IPv6 tunneling, the quality of IPv4 connectivity is decreasing
    • DS-Lite
    • 464XLAT
  • IPv4 might be broken for users on the Internet

IPv6 Service offerings must work IPv6-only

  • Internet-User with broken IPv4 are using an IPv6-only Internet
  • Websites and other Internet Services must work in this IPv6-only scenario
  • Test external facing services in IPv6-only mode
    • Websites (do all resources load over IPv6?)
    • API Endpoints
    • Authoritative DNS server
    • SMTP Mail

Purchase of ITC Equipment

Purchase of ITC Equipment

  • RFPs, Contracts, etc: All products, support sites, etc MUST NOT require IPv4
    • Communicate to vendors early to give them time to find and fix problems
    • Get confirmation about IPv6(-only) support (RFC 8504) in writing from vendors

Purchase of ITC Equipment

Questions?
