IPv6 Security

Agenda

• IPv6 Security Issues
• Tools

IPv6 Security Issues

Security and IPv6

• IPv6 is now over 25 years old
  • It inherits many design decisions from IPv4
  • It also inherits the security shortcomings from IPv4
  • Most IPv6 security issues are also available on IPv4
  • Some IPv4 security issues don't exist on IPv6
  • Some new security issues have been introduced by IPv6
• ISOC IPv6 Security FAQ (PDF)
• RFC 9099 "Operational Security Considerations for IPv6 Networks"

ICMPv6 neighbor solicitation/advertisement spoofing

• Neighborhood Discovery is un-authenticated
  • An "on-link" attacker can spoof or alter ND messages
  • DoS attacks (e.g. Duplicate Address Detection DoS)
  • MITM attacks
    • spoofed Address Resolution Responses
    • Router Redirection spoofing
• RFC 3756 "IPv6 Neighbor Discovery (ND) Trust Models and Threats"

ICMPv6 neighbor solicitation/advertisement spoofing

• Possible mitigation
  • Secure Neighborhood Discovery (SeND) RFC 3971 "SEcure Neighbor Discovery (SEND)"
    • Unfortunately, SeND is not well supported by current Operating Systems and difficult to deploy
• Host isolation - assigning a /64 prefix per node
  • all communication must pass though a router (that should be a filtering device), no direct node-to-node traffic is permitted
  • RFC 8273 "Unique IPv6 Prefix per Host"

Router spoofing

• Attacker (for example via malware/trojan software) can activate a "fake" router in the network
  • Denial-Of-Service attack
  • Men-in-the-Middle (MITM) attack
• RFC 6104 "Rogue IPv6 Router Advertisement Problem Statement"

Router spoofing

• Possible mitigation
  • Secure Neighborhood Discovery (SeND) RFC 3971 "SEcure Neighbor Discovery (SEND)"
    • Unfortunately, SeND is not well supported by current Operating Systems and difficult to deploy
  • RFC 6105 "IPv6 Router Advertisement Guard"

DHCP spoofing

• Attacker can launch malicious DHCPv6 server (via malware/trojan software)
  • Distribute wrong network configuration
  • Distribute wrong IPv6 addresses
  • Creates MITM and DoS attack possibilities
• Mitigation
  • "DHCP Shield" in Layer 2 devices
  • RFC 7610 "DHCPv6-Shield: Protecting against Rogue DHCPv6 Servers"

Spoofed DNS Resolver in Router Advertisements

• Router Advertisements (RA) messages are not authenticated
  • Attacker can spoof this messages with any content
  • The RA can contain the IP-Addresses of DNS resolver to be used
  • By changing the DNS resolver of clients, an attacker can redirect or manipulate network traffic

Spoofed DNS Resolver in Router Advertisements

• Mitigation
  • Use of DNSSEC for security critical domains (e.g. internal Active Directory)
  • Use of authenticated DNS-over-TLS/DNS-over-HTTPS (using x509 certificates)
  • Distribute manual configured DNS resolver addresses (through configuration management systems)
  • Use of manual configured site-local multicast addresses for DNS resolver

Router/Neighborhood Advertisements Flooding (DoS)

• Attackers can trigger a high number of Neighborhood-Discovery (ND) events from a Router or from network devices, for example through a network scan
  • The high number of events can create a denial-of-service attack onto the router infrastructure
• Mitigation strategies
  • Rate-Limiting of ND events
  • Filter (parts of) the unused address space
  • For Router-to-Router connections, use a /127 network prefix
  • Using only link-local addresses on links where there are only routers
• RFC 6583 "Operational Neighbor Discovery Problems"

Extension Header attacks

• Creative use of extension headers can create security issues
  • Nested fragmentation
  • Fragmented Extension Headers
  • Overlapping Extension Headers
• Can be used to bypass security appliances and firewalls
• Stealth Data exfiltration via Extension Headers
• IPv6 Extension Headers - New Features, and New Attack Vectors
• RFC 9098 - "Operational Implications of IPv6 Packets with Extension Headers"

Extension Header attacks

• Packets containing wrongly formatted IPv6 extension headers can result in nodes crashing when processing the headers
• A firewall or edge device should be used to enforce the recommended order and the maximum occurrences of extension headers by dropping nonconforming packets
• RFC 9288 - "Recommendations on the Filtering of IPv6 Packets Containing IPv6 Extension Headers at Transit Routers"
• Firewalls based on OpenBSD (pf), Linux "nftables" or eBPF, are to be a good choice

Fragmentation Attacks

• Stateless filtering in firewalls can be bypassed by creative use of IPv6 fragmentation headers
• Firewall and security devices should drop first fragments that do not contain the entire IPv6 header chain (including the transport-layer header)
• Destination nodes should discard first fragments that do not contain the entire IPv6 header chain (including the transport-layer header).
• RFC 6980 "Security Implications of IPv6 Fragmentation with IPv6 Neighbor Discovery"

IPv6 Address Scanning

• it is widely assumed that it would take a huge effort to perform address-scanning attacks against IPv6 networks
  • IPv6 address-scanning attacks have been considered unfeasible
• However based on the "randomness" of the source of IPv6 Interface-IDs, IPv6 address-canning might be possible
  • Manual continuous address assignment
  • IPv6 Interface IDs from "well-known" Hardware-Addresses
  • DHCPv6 Host "reservations"
  • Node-Information-Queries over ICMPv6

IPv6 Address Scanning

• Security should not rely on hiding IPv6 addresses in the vast IPv6 address space (aka "Security by Obscurity")
• See
  • RFC 7707 "Network Reconnaissance in IPv6 Networks"
  • "Mapping the Great Void - Smarter scanning for IPv6", February 2012 (PDF)

Security Implications of Dual-Stack Networks

• Running IPv6 and IPv4 in the same network (aka "Dual-Stack") can create it's own security issues
  • Attacker can choose the weakest protocol
  • Attacker can tunnel one Protocol inside the other to hide
• Security policies need to in sync between IPv6 and IPv4 (Firewall rules, Intrusion Detection systems)
  • Firewalls should allow a common ruleset for IPv6 and IPv4 (use "nftables" not "iptables" on Linux)

Security Implications of Dual-Stack Networks

• Control or block Protocol tunnel technologies (see RFC 9099 for guidance)
• See
  • RFC 4942 "IPv6 Transition/Coexistence Security Considerations"
  • RFC 7123 "Security Implications of IPv6 on IPv4 Networks"
  • RFC 7359 - Layer 3 Virtual Private Network (VPN) Tunnel Traffic Leakages in Dual-Stack Hosts/Networks

Tools

The Hackers Choice IPv6 Toolkit

• The Hackers Choice IPv6 Toolkit is a collection of Linux/Unix command line tools to test the security properties of IPv6 networks
  • "The Hacker's Choice" IPv6 toolkit: https://www.thc.org/
    • Sources: https://github.com/vanhauser-thc/thc-ipv6.git
  • As these tools can also be mis-used for attacks, be careful when using them to test foreign networks

SI6 Toolkit

• A set of IPv6 security assessment and trouble-shooting tools:
  • https://www.si6networks.com/research/tools/ipv6toolkit/

Chiron

• Chiron is an IPv6 Security Assessment Framework, written in Python and employing Scapy
  • IPv6 Scanner
  • IPv6 Local Link Security Tests
  • IPv4-to-IPv6 Proxy
  • IPv6 Attack Module
  • IPv6 Proxy
• Source: https://github.com/aatlasis/Chiron

Conclusion

Conclusion

• IPv6 is neither more, nor less secure compared to IPv4
• In Dual-Stack networks, Administrators have to deal with security issues of both protocols
  • Attacker have twice the attack space
  • A motivation to move to IPv6-only networks sooner (remove IPv4 where possible)

Questions?
